BLASTOMERE BIOPSY PIPETTES(顯微囊胚活檢針)

• 顯微囊胚活檢針用於從胚胎中移除囊胚和滋養外胚層細胞，以進行植入前遺傳診斷 (PGD)。
• 顯微囊胚活檢針有兩種吸頭樣式：扁平或斜
• 顯微囊胚活檢針可根據內直徑和吸頭角度進一步定制
• 建議用於滋養層外胚層 (TE) 活檢的內直徑為 20 µm 和 25 µm
• 彎曲處不會收縮，因此在囊胚被吸穿的情況下，對囊胚造成損害的可能性不大
• 尖端經火拋光處理，以減少對細胞膜的損害

分享到

商品特色

BLASTOMERE BIOPSY PIPETTES

• Blastomere biopsy pipettes are used to remove blastomeres and trophectoderm cells from embryos for pre-implantation genetic diagnosis (PGD).

• These pipettes come in 2 tip styles: flat or beveled.

• Pipettes can be further customized by inner diameter and tip angle.

• Inner diameters of 20 µm and 25 µm are recommended for trophectoderm (TE) biopsy.

• There is no shrinkage at the bend so damage to the blastomere is unlikely in the case that it is sucked through.

• Tips are fire polished to reduce damage to the cell membrane.

PRODUCT	CATALOG NUMBER	FINISH STYLE	INNER DIAMETER	OUTER DIAMETER	TIP ANGLE	TOE LENGTH
Blastomere Biopsy Pipettes	SBB-20X-00	Beveled	18-22 µm	21-25 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-20X-05	Beveled	18-22 µm	21-25 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-10	Beveled	18-22 µm	21-25 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-15	Beveled	18-22 µm	21-25 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-20	Beveled	18-22 µm	21-25 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-25	Beveled	18-22 µm	21-25 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-30	Beveled	18-22 µm	21-25 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-35	Beveled	18-22 µm	21-25 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-40	Beveled	18-22 µm	21-25 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20X-45	Beveled	18-22 µm	21-25 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-00	Flat	18-22 µm	21-25 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-20Z-05	Flat	18-22 µm	21-25 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-10	Flat	18-22 µm	21-25 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-15	Flat	18-22 µm	21-25 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-20	Flat	18-22 µm	21-25 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-25	Flat	18-22 µm	21-25 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-30	Flat	18-22 µm	21-25 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-35	Flat	18-22 µm	21-25 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-40	Flat	18-22 µm	21-25 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-20Z-45	Flat	18-22 µm	21-25 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-00	Beveled	23-27 µm	26-30 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-25X-05	Beveled	23-27 µm	26-30 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-10	Beveled	23-27 µm	26-30 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-15	Beveled	23-27 µm	26-30 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-20	Beveled	23-27 µm	26-30 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-25	Beveled	23-27 µm	26-30 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-30	Beveled	23-27 µm	26-30 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-35	Beveled	23-27 µm	26-30 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-40	Beveled	23-27 µm	26-30 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25X-45	Beveled	23-27 µm	26-30 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-00	Flat	23-27 µm	26-30 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-25Z-05	Flat	23-27 µm	26-30 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-10	Flat	23-27 µm	26-30 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-15	Flat	23-27 µm	26-30 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-20	Flat	23-27 µm	26-30 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-25	Flat	23-27 µm	26-30 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-30	Flat	23-27 µm	26-30 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-35	Flat	23-27 µm	26-30 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-40	Flat	23-27 µm	26-30 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-25Z-45	Flat	23-27 µm	26-30 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-00	Beveled	28-32 µm	31-35 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-30X-05	Beveled	28-32 µm	31-35 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-10	Beveled	28-32 µm	31-35 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-15	Beveled	28-32 µm	31-35 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-20	Beveled	28-32 µm	31-35 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-25	Beveled	28-32 µm	31-35 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-30	Beveled	28-32 µm	31-35 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-35	Beveled	28-32 µm	31-35 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-40	Beveled	28-32 µm	31-35 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30X-45	Beveled	28-32 µm	31-35 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-00	Flat	28-32 µm	31-35 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-30Z-05	Flat	28-32 µm	31-35 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-10	Flat	28-32 µm	31-35 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-15	Flat	28-32 µm	31-35 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-20	Flat	28-32 µm	31-35 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-25	Flat	28-32 µm	31-35 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-30	Flat	28-32 µm	31-35 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-35	Flat	28-32 µm	31-35 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-40	Flat	28-32 µm	31-35 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-30Z-45	Flat	28-32 µm	31-35 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-00	Beveled	33-37 µm	36-40 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-35X-05	Beveled	33-37 µm	36-40 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-10	Beveled	33-37 µm	36-40 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-15	Beveled	33-37 µm	36-40 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-20	Beveled	33-37 µm	36-40 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-25	Beveled	33-37 µm	36-40 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-30	Beveled	33-37 µm	36-40 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-35	Beveled	33-37 µm	36-40 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-40	Beveled	33-37 µm	36-40 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35X-45	Beveled	33-37 µm	36-40 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-00	Flat	33-37 µm	36-40 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-35Z-05	Flat	33-37 µm	36-40 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-10	Flat	33-37 µm	36-40 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-15	Flat	33-37 µm	36-40 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-20	Flat	33-37 µm	36-40 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-25	Flat	33-37 µm	36-40 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-30	Flat	33-37 µm	36-40 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-35	Flat	33-37 µm	36-40 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-40	Flat	33-37 µm	36-40 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-35Z-45	Flat	33-37 µm	36-40 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-00	Beveled	38-42 µm	41-45 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-40X-05	Beveled	38-42 µm	41-45 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-10	Beveled	38-42 µm	41-45 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-15	Beveled	38-42 µm	41-45 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-20	Beveled	38-42 µm	41-45 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-25	Beveled	38-42 µm	41-45 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-30	Beveled	38-42 µm	41-45 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-35	Beveled	38-42 µm	41-45 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-40	Beveled	38-42 µm	41-45 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40X-45	Beveled	38-42 µm	41-45 µm	45°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-00	Flat	38-42 µm	41-45 µm	n/a	n/a
Blastomere Biopsy Pipettes	SBB-40Z-05	Flat	38-42 µm	41-45 µm	5°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-10	Flat	38-42 µm	41-45 µm	10°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-15	Flat	38-42 µm	41-45 µm	15°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-20	Flat	38-42 µm	41-45 µm	20°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-25	Flat	38-42 µm	41-45 µm	25°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-30	Flat	38-42 µm	41-45 µm	30°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-35	Flat	38-42 µm	41-45 µm	35°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-40	Flat	38-42 µm	41-45 µm	40°	0.55 mm
Blastomere Biopsy Pipettes	SBB-40Z-45	Flat	38-42 µm	41-45 µm	45°	0.55 mm
